Description
Download the app to connect and monitor your SOK Battery.
Search ABC-BMS on google or apple store, download and install.
Please note: SOC is initially incorrect, it takes 2 full charge / discharge cycles to reach proper calibration.
Please check here for details.
7 year warranty and maintenance free with a 3000-8000 cycles life span.
Detachable cover with replaceable BMS and cells.
Built-in heater pad for using in down to -4°F.
Bluetooth4.0 , supprot IPhone or Android smartphone.
Support connect in parallel for larger capacity.
Built-in smart Battery Management System (BMS).
Low temperature charging cut-off.
High temperature charging or discharging cut-off.
Over charging and discharging protection.
Over current and short circuit protection.
Battery cells auto balance.
Please note for connecting in series: NOT OVER 4 Batteries IN SERIES, and make sure add the battery voltage balancer.
Spec information
Charge information:
Recommended Charge Current 40 A
Maximum Charge Current 70 A
Recommended Charge Voltage 14.6 V
Discharge information
Maximum Continuous Discharge Current 170 A
Peak Discharge Current 200 A (3 s)
Recommended Low Voltage Disconnect 10.4V
Size Information:
Terminal Type: M8, 5/16 lugs
Weight: 48 lbs.
Temperature Information:
Discharge Temperature -4 to 140 ºF
Charge Temperature -4 to 113 ºF
Storage Temperature 23 to 95 ºF
Certifications Information:
UL1973&IEC62619 for Battery cells.
